| Logic Board |
Ports |
Power |
| Processor: |
68LC040, 25 MHz |
| PMMU: |
integrated |
| FPU: |
none |
| Data Path: |
32-bit, 25 MHz |
| L1 Cache: |
8K |
| L2 Cache: |
none |
| 2nd Processor: |
none |
| Slots: |
1 LC III PDS |
|
| USB: |
|
| ADB: |
1 |
| Video: |
DB-15 |
| Floppy: |
none |
| SCSI: |
DB-25 |
| Geoports: |
none |
| Ethernet: |
none |
| FireWire: |
|
| Mic Type: |
PlainTalk |
| Other Ports: |
Printer, Modem, Speaker,
|
|
| Max Watts: |
30 |
| Amps: |
0.44 |
| BTU per Hr: |
102.6 |
| Voltage: |
100-240 |
| Freq Range: |
47-63 Hz |
| Battery Type: |
3.6V lithium |
|
| Memory |
Video Memory |
| Logic Board: |
4 MB |
| RAM Slots: |
1, 72-pin SIMM |
| Min - Max RAM: |
4 MB - 36 MB |
| Min RAM Speed: |
80 ns |
| RAM Sizes: |
1, 2, 4, 8, 16, 32 MB |
| Install in Groups of: |
1 |
|
| Resolution |
Video Memory
512K VRAM
(2x256K ) |
Video Memory
1MB VRAM
(2x512K) |
| 512 x 384 |
16-bit |
16-bit |
| 640 x 400 |
n/a-bit |
n/a-bit |
| 640 x 480 |
8-bit |
16-bit |
| 800 x 600 |
n/a-bit |
n/a-bit |
| 832 x 624 |
8-bit |
16-bit |
| 1024 x 768 |
4-bit |
8-bit |
| 1152 x 870 |
4-bit |
8-bit |
| 1280 x 1024 |
n/a-bit |
n/a-bit |
|
| Physical |
Software |
Storage |
| Introduced: |
10/21/1993 |
| Discontinued: |
10/17/1994 |
| Form Factor: |
LC |
| Gestalt ID: |
94 |
| Weight (lbs): |
8.8 |
| Dimensions (in): |
2.9 H x 12.2 W x 15.3 D |
|
| Addressing Modes: |
24-, 32-bit |
| Orig SSW: |
7.1 |
| Orig Enabler: |
System Enabler 065 |
| ROM ID: |
$067C |
| ROM Ver: |
n/a |
| ROM Size: |
512k* |
| AppleTalk Ver: |
57.0.4 |
Mac OS
Supported: |
7.1
7.5
7.1.1 (Pro)
7.5.1
7.5.3
7.5.5
7.6
7.6.1
8.0
8.1 |
| Notes: |
ROM = 512k: expandable to 1MB |
|
| Floppy Size: |
1.44MB |
| Floppy Inject: |
manual |
| Min. Int HD Size: |
80-160MB |
| Int HD Interface: |
SCSI |
| Orig CD Speed |
n/a |
| Int CD Support: |
|
|
|
