| Logic Board |
Ports |
Power |
| Processor: |
603, 75 MHz |
| PMMU: |
integrated |
| FPU: |
integrated |
| Data Path: |
64-bit, 37.5 MHz |
| L1 Cache: |
16K |
| L2 Cache: |
256K |
| 2nd Processor: |
none |
| Slots: |
LC, comm, TV, video in/out |
|
| USB: |
|
| ADB: |
1 |
| Video: |
DB-15 |
| Floppy: |
none |
| SCSI: |
DB-25 |
| Geoports: |
none |
| Ethernet: |
none |
| FireWire: |
|
| Mic Type: |
PlainTalk |
| Other Ports: |
Printer, Modem, Speaker,
Headphone,
Remote Control
|
| Sound Notes: |
INPUT: impedance 100 kOhm; avg. line level 100 mV rms; avg. mic. level 70 mV rms, max. input level 1.8 V rms |
|
| Max Watts: |
150 |
| Amps: |
1.25 |
| BTU per Hr: |
513 |
| Voltage: |
100-240 |
| Freq Range: |
50-60 Hz |
| Battery Type: |
4.5V alkaline |
| Soft Power: |
yes |
|
| Memory |
Video Memory |
| Logic Board: |
none |
| RAM Slots: |
2, 72-pin SIMM |
| Min - Max RAM: |
8 MB - 64 MB |
| Min RAM Speed: |
80 ns |
| RAM Sizes: |
4, 8, 16, 32 MB |
| Install in Groups of: |
1 |
|
| Resolution |
Video Memory
1MB DRAM
(built in) |
| 512 x 384 |
n/a-bit |
| 640 x 400 |
n/a-bit |
| 640 x 480 |
16-bit |
| 800 x 600 |
8-bit |
| 832 x 624 |
8-bit |
| 1024 x 768 |
n/a-bit |
| 1152 x 870 |
n/a-bit |
| 1280 x 1024 |
n/a-bit |
Notes: Video in not supported at 832x624. |
| Physical |
Software |
Storage |
| Introduced: |
5/1/1995 |
| Discontinued: |
n/a |
| Form Factor: |
Quadra 630 |
| Gestalt ID: |
42 |
| Weight (lbs): |
19 |
| Dimensions (in): |
4.3 H x 12.6 W x 16.5 D |
| Notes: |
This system is not sold in the U.S. |
|
| Addressing Modes: |
32-bit |
| Orig SSW: |
7.5.1 |
| Orig Enabler: |
System Enabler 406 |
| ROM ID: |
$077D |
| ROM Ver: |
$26 |
| ROM Size: |
4MB |
| AppleTalk Ver: |
58.1.3 |
Mac OS
Supported: |
7.5.1
7.5.3
7.5.5
7.6
7.6.1
8.0
8.5
8.1 |
|
| Floppy Size: |
1.44MB |
| Floppy Inject: |
manual |
| Min. Int HD Size: |
500MB |
| Int HD Interface: |
IDE |
| Orig CD Speed |
4x |
| Int CD Support: |
yes |
|
|
