| Logic Board |
Ports |
Power |
| Processor: |
603e, 250 MHz |
| PMMU: |
integrated |
| FPU: |
integrated |
| Data Path: |
64-bit, 50 MHz |
| L1 Cache: |
32K |
| L2 Cache: |
256K |
| 2nd Processor: |
none |
| Slots: |
2 PCI, Comm II, TV, video in |
| Notes: |
Some models ship with a modem in the comm slot II. |
|
| USB: |
|
| ADB: |
1 |
| Video: |
DB-15 |
| Floppy: |
none |
| SCSI: |
DB-25 |
| Geoports: |
2 |
| Ethernet: |
10baseT |
| FireWire: |
|
| Mic Type: |
PlainTalk |
| Other Ports: |
Printer, Modem, Speaker,
Headphone,
Remote Control
|
|
| Max Watts: |
220 |
| Amps: |
3.00 |
| BTU per Hr: |
752.4 |
| Voltage: |
100-125/200-240 |
| Freq Range: |
47-63 Hz |
| Battery Type: |
4.5V alkaline |
| Soft Power: |
yes |
| Pass Through: |
yes |
|
| Memory |
Video Memory |
| Logic Board: |
none |
| RAM Slots: |
2, 168-pin DIMM |
| Min - Max RAM: |
32 MB - 128 MB |
| Min RAM Speed: |
60 ns |
| RAM Sizes: |
4, 8, 16, 32, 64 MB |
| Install in Groups of: |
1 |
|
| Resolution |
Video Memory
2MB SGRAM
(built in) |
| 512 x 384 |
24-bit |
| 640 x 400 |
n/a-bit |
| 640 x 480 |
24-bit |
| 800 x 600 |
24-bit |
| 832 x 624 |
24-bit |
| 1024 x 768 |
16-bit |
| 1152 x 870 |
16-bit |
| 1280 x 1024 |
8-bit |
|
| Physical |
Software |
Storage |
| Introduced: |
2/17/1997 |
| Discontinued: |
n/a |
| Form Factor: |
Performa 6400 |
| Gestalt ID: |
513 |
| Weight (lbs): |
44.5 |
| Dimensions (in): |
16 H x 7.8 W x 16.9 D |
|
| Addressing Modes: |
32-bit |
| Orig SSW: |
7.5.5 |
| Orig Enabler: |
System Enabler 411 |
| ROM ID: |
$077D |
| ROM Ver: |
$35 |
| ROM Size: |
4MB |
| AppleTalk Ver: |
60.1.1 |
Mac OS
Supported: |
7.5.5
7.6.1
8.0
8.1
8.5 |
|
| Floppy Size: |
1.44MB |
| Floppy Inject: |
manual |
| Min. Int HD Size: |
3, 4GB |
| Int HD Interface: |
ATA |
| Orig CD Speed |
12x, 24x |
| Int CD Support: |
yes |
| Notes: |
Some systems ship with an Iomega Zip drive. |
|
|
