| Logic Board |
Ports |
Power |
| Processor: |
G3, 233 MHz |
| PMMU: |
integrated |
| FPU: |
integrated |
| Data Path: |
, |
| L1 Cache: |
32K |
| L2 Cache: |
512K |
| 2nd Processor: |
none |
| Slots: |
0 |
| Notes: |
512k backside cache memory |
|
| USB: |
2 |
| ADB: |
n/a |
| Video: |
none |
| Floppy: |
none |
| SCSI: |
none |
| Geoports: |
none |
| Ethernet: |
10/100 Base-Tx |
| FireWire: |
|
| Mic Type: |
PlainTalk |
| Other Ports: |
Modem, Speaker,
Headphone,
|
| Sound Notes: |
built-in stereo speakers with SRS 3D stereo sound |
|
| Max Watts: |
80 |
| Amps: |
1.7 |
| BTU per Hr: |
273.6 |
| Voltage: |
100-240 |
| Freq Range: |
50-60 Hz |
| Battery Type: |
3.6V Lithium |
| Soft Power: |
yes |
|
| Memory |
Video Memory |
| Logic Board: |
none |
| RAM Slots: |
2, SO-DIMM |
| Min - Max RAM: |
32 MB - 128 MB |
| Min RAM Speed: |
100MHz/10ns |
| RAM Sizes: |
16, 32, 64, 128 MB |
| Install in Groups of: |
1 |
| Notes: |
144-pin SDRAM M6709LL/A = 32MB - 128MB M6709LL/B = 32MB - 256MB |
|
| Resolution |
Video Memory
2MB (onboard)
(SGRAM) |
Video Memory
6MB
(SGRAM) |
| 512 x 384 |
n/a |
n/a |
| 640 x 400 |
n/a |
n/a |
| 640 x 480 |
32-bit |
32-bit |
| 800 x 600 |
32-bit |
32-bit |
| 832 x 624 |
n/a |
n/a |
| 1024 x 768 |
16-bit |
32-bit |
| 1152 x 870 |
n/a |
n/a |
| 1280 x 1024 |
n/a |
n/a |
Notes: 144-pin SGRAM NOTE: use only a SGRAM SO-DIMM. Do NOT use EDO DRAM or SDRAM-based video memory. |
| Physical |
Software |
Storage |
| Introduced: |
8/15/1998 |
| Discontinued: |
n/a |
| Form Factor: |
iMac |
| Gestalt ID: |
406 |
| Weight (lbs): |
40 |
| Dimensions (in): |
15.8 H x 15.2 W x 17.6 D |
| Notes: |
IrDA infrared link module 4 Mb/s transfer rate; range = 2 inches to 1 meter |
|
| Addressing Modes: |
32-bit |
| Orig SSW: |
8.1/8.5 |
| Orig Enabler: |
462 |
| ROM ID: |
77D |
| ROM Ver: |
44F1 |
| ROM Size: |
1 MB* |
| AppleTalk Ver: |
60 |
Mac OS
Supported: |
8.1
8.5 |
| Notes: |
*uses 3MB of RAM for toolbox ROM |
|
| Floppy Size: |
none |
| Floppy Inject: |
none |
| Min. Int HD Size: |
4 GB |
| Int HD Interface: |
ATA |
| Orig CD Speed |
24x |
| Int CD Support: |
yes |
| Notes: |
Keyboard, Mouse have USB interface Supports ATA CD-ROM |
|
|
