In the Box

• iMac
• Apple Keyboard
• Mighty Mouse
• Apple Remote⁽¹⁾
• Power cord
• Install/restore DVDs
• Printed and electronic documentation

Processor and memory

• 1.83GHz, 2GHz, 2.16GHz or 2.33GHz Intel Core 2 Duo processor
• 4MB shared L2 cache at full processor speed on iMac with 2GHz, 2.16Ghz, or 2.33GHz Intel Core 2 Duo processor
• 2MB shared L2 cache at full processor speed on iMac with 1.83GHz Intel Core 2 Duo processor
• 667MHz system bus
• 17-inch iMac with 1.83GHz processor
• 512MB (2x256MB) of PC2-5300 (667MHz) DDR2 memory
• Two SODIMM slots support up to 2GB
• 17-inch model with 2.0GHz processor, 20-inch and 24-inch models
• 1GB (2x512MB) of PC2-5300 (667MHz) DDR2 memory
• Two SODIMM slots support up to 3GB

Storage

• 17-inch model
• 160GB Serial ATA 7200-rpm hard drive
• Optional 250- and 500GB Serial ATA 7200-rpm hard drives on model with 2.0GHz processor
• 20-inch and 24-inch models
• 250GB Serial ATA 7200-rpm hard drive ⁽²⁾
• Optional 500GB Serial ATA 7200-rpm hard drive
• 17-inch model with 1.83GHz processor with slot-loading 24x Combo drive (DVD-ROM/CD-RW)
• Reads DVDs at up to 8x speed
• Writes CD-R discs at up to 24x speed
• Writes CD-RW discs at up to 16x speed
• Reads CDs at up to 24x speed
• 17-inch model with 2.0GHz processor, 20-inch model and 24-inch model with slot-loading 8x SuperDrive (DVD+R DL/DVD±RW/CD-RW)
• Writes DVD+R DL discs at up to 2.4x speed
• Writes DVD-R and DVD+R discs at up to 8x speed
• Writes DVD-RW and DVD+RW discs at up to 4x speed
• Reads DVDs at up to 8x speed
• Writes CD-R discs at up to 24x speed
• Writes CD-RW discs at up to 16x speed
• Reads CDs at up to 24x speed

Communications

• Built-in 54-Mbps AirPort Extreme Card (802.11g standard) ⁽³⁾
• Built-in Bluetooth 2.0+EDR (Enhanced Data Rate) module
• Built-in 10/100/1000 BASE-T Gigabit Ethernet (RJ-45 connector)
• Works with 56K V.92 Apple USB Modem (sold separately)

Display

• Built-in 17-inch (viewable), 20-inch (viewable), or 24-inch (viewable) widescreen TFT active-matrix liquid crystal display
• Millions of colours at all resolutions
• Typical viewing angle:
  • 17-inch model
    • 140° horizontal
    • 120° vertical
  • 20-inch model
    • 170° horizontal
    • 170° vertical
  • 24-inch model
    • 178° horizontal
    • 178° vertical
• Typical brightness: 250 cd/m (17-inch model); 280 cd/m (20-inch model); 400 cd/m (24-inch model)
• Typical contrast ratio: 500:1 (17-inch model); 800:1 (20-inch and 24-inch models)

Graphics and Video

• 17-inch model with 1.83GHz processor
• Intel GMA 950 graphics processor with 64MB of DDR2 SDRAM shared with main memory
• 17-inch model with 2.0 GHz processor and 20-inch model
• ATI Radeon X1600 graphics processor using PCI Express
• 128MB of GDDR3 memory
• Optional 256MB of GDDR3 memory
• 24-inch model
• NVIDIA GeForce 7300 GT graphics processor with 128MB of GDDR3 memory using PCI Express
• Optional NVIDIA GeForce 7600 GT graphics processor with 256MB of GDDR3 memory using PCI Express
• Mini-DVI output port with support for DVI, VGA, S-video, and composite video connections via adapter⁽⁴⁾

• Built-in iSight camera
• Support for external display in extended desktop
  • Digital resolutions up to 1920 x 1200
  • Analogue resolutions up to 2045 x 1536
• Support for external display in video mirroring mode

Electrical and environmental requirements

• Meets ENERGY STAR requirements
• Line voltage: 100-240V AC

• Frequency: 50Hz to 60Hz, single phase
• Maximum continuous power: 180W (17- and 20-inch models); 220W (24-inch model)
• Operating temperature: 10° to 35° C (50° to 95° F)
• Storage temperature: -40° to 85° C (-40° to 185° F)
• Relative humidity: 5% to 95% noncondensing
• Maximum altitude: 3,000 m (10,000 feet)

Size and weight (17-inch)

• Height: 43.0 cm (16.9 inches)
• Width: 42.6 cm (16.8 inches)
• Depth: 17.3 cm (6.8 inches)
• Weight: 7 kg (15.5 pounds)⁽⁵⁾

Size and weight (20-inch)

• Height: 47.2 cm (18.6 inches)
• Width: 49.3 cm (19.4 inches)
• Depth: 18.9 cm (7.4 inches)
• Weight: 10 kg (22 pounds)⁽⁵⁾

Size and weight (24-inch)

• Height: 52.3 cm (20.6 inches)
• Width: 57.4 cm (22.6 inches)
• Depth: 20.7 cm (8.1 inches)
• Weight: 11.2 kg (24.7 pounds)⁽⁵⁾

Peripheral connections

• 17-inch and 20-inch models
• Two FireWire 400 ports; 8 watts shared
• 24-inch model
• One FireWire 400 and one FireWire 800 port; 15 watts shared
• Total of five USB ports: three USB 2.0 ports (up to 480 Mbps) on computer, two USB 1.1 ports on keyboard

Audio

• Built-in stereo speakers
• 17-inch and 20-inch models
• Internal 12-watt digital amplifier
• 24-inch model
• Internal 24-watt digital amplifier
• Headphone/optical digital audio output (minijack)
• Audio line in/optical digital audio input (minijack)
• Built-in microphone

Software

• Mac OS X v10.4 Tiger (includes Spotlight, Dashboard, Mail, iChat AV, Safari, Address Book, QuickTime, iCal, DVD Player, Xcode Developer Tools)
• iLife ’06 (includes iTunes, iPhoto, iMovie HD, iDVD, iWeb, GarageBand), Microsoft Office 2004 for Mac Test Drive, iWork (30-day trial), Big Bang Board Games, Comic Life, Omni Outliner, and Apple Hardware Test
• Front Row
• Photo Booth
